Cybex 530C and 530R Owner’s Manual
Preventive
Maintenance
Page 4-7
B. Remove the front cap.
C. Remove the four screws securing the top cap in place. Remove top cap. See Figure 10.
D. Remove the seven screws securing the right cover in place. Remove right cover. See Figure 10.
E. Remove the two screws securing the left cover in place. Remove left cover. See Figure 10.
Front Cap
Left Cover
Top Cap
Screws (4)
Screws (7)
Figure 10
Right Cover
