9. Install the right top step by placing in position and inserting a long 3/8" drive socket extension into
the right top step.
Qty.Description
13/8" Drive Socket Extension1
1Right Top Step2
10. Pry the long 3/8" drive socket extension forwards to secure the right top step.
11. Using a Phillips screwdriver, install the two screws securing the right end cap.
Install uprights
1. Install the short and long standoffs to the right side of the base using a 3/4" open end wrench.
Qty.Description
1Standoff, short1
1Standoff, long2
1Base3
1Front of unit4
2. Thread two bolts into the base by hand. Do not fully thread bolts into the base.
Qty.Description
1Upright (Right shown)1
1Base2
2Bolt, Whiz lock3
3. Place the right upright onto the base assembly and the bolts installed in the previous step.
Page 21 of 88
Cybex 625T Treadmill Part Number LT-23221-4 H
