Cybex 750T Treadmill Service Manual
Parts List
Page A-2
ITEM QTY. PART NO. DESCRIPTION
116 1 AW-20289 WIRE, INLET TO SWITCH FILTER
JUMPER
117 1 AW-20290 WIRE, SWITCH TO FILTER
JUMPER
118 1 AW-20291 WIRE, INLET TO GROUND
JUMPER, GREEN
119 1 AW-22177 CABLE, MOTOR CONTROLLER
120 1 AW-20442 WIRE, FILTER TO OUTLET
JUMPER, BLACK
121 1 AW-20443 WIRE, FILTER TO OUTLET
JUMPER, WHITE
122 1 AW-20444 WIRE, OUTLET, GROUND JUMPER,
GREEN
123 1 AW-20446 WIRE, INLET TO SWITCH JUMPER,
BLACK
124 1 AW-20447 WIRE, INLET TO SWITCH JUMPER,
WHITE
125 1 CN-20252 PLUG, NEMA 5-15R
126 1 DE-20558 LABEL, HUB BOARD
127 1 EC-18896 FILTER, 16A
128 1 EH-12208 INLET, IEC, 320 16-20 AMP
130 1 FS-20232 BRACKET, POWER CORD
RETAINER
131 2 HN-11925 KEPS, 10-32, HEX, STL, ZN
132 2 HS-10405 SCREW, 4-40 X .25”,PNHD PHIL
134 4 HS-15732 SCREW, SEMS, 8-32 UNC X .62”,
PNHD, PHIL
135 1 HW-10856 WASHER, LOCK, EXTERNAL, NO.
10
136 1 RE-20242 RESISTOR, TM5, DYNAMIC
BRAKE
137 1 SW-19666 SWITCH, CIRCUIT BREAKER, 15
AMP, 240 VAC
137 1 SW-19667 SWITCH, CIRCUIT BREAKER, 20
AMP, 240 VAC
200 1 AF-19890 WELDMENT, FRAME
201 1 AF-19921 WELDMENT, UPRIGHT, LEFT
202 1 AF-19922 WELDMENT, UPRIGHT, RIGHT
203 1 AX-20331 ASSY, TOP PLATFORM, LEFT
204 1 AX-20332 ASSY, TOP PLATFORM, RIGHT
205 2 DE-20305 DECAL, SAFETY WALK
300 1 AC-21401-X* ASSY, CONSOLE, 751T, AMBER
LED
302 1 AF-21761 WELDMENT, CONSOLE
303 1 AW-19694 CABLE, HANDSET TO DISPLAY
304 1 AW-20170 CABLE, MOTION SENSOR
305 1 AW-20239 CABLE, 750T CONSOLE
306 1 AX-19936 ASSY, HANDRAIL, LEFT
307 1 AX-19941 ASSY, HANDRAIL, RIGHT
309 1 AX-20552 ASSY, E-STOP KEY
311 1 DE-20364 DIFFUSER, DISC, 0.6” OD
312 1 DE-21184 DECAL, 751T, CONSOLE, TOP,
AMBER LED, LANGUAGES
312 1 DE-21184-4 DECAL, 751T, CONSOLE, TOP,
AMBER LED, ENGLISH
313 1 EC-19706 FAN, 12 VDC, 120 X 120MM
314 1 EC-19974 SENSOR, IR MOTION
315 4 HN-20362 NUT, SELF THREADING, 3/8 X
11/16”, ST
316 2 HS-10716 SCREW, 4-40 X 0.38”, PNHD, PHIL
317 4 HS-14391 SCREW, 6-32 X .38, PNHD, PHIL
319 8 HS-18320 SCREW, 6-19 X 1-2”, PNHD, PHIL
321 2 HS-20367 SCREW, SEMS, M4 X 10 mm,
PNHD, PHIL
322 3 HS-20399 SCREW, SEMS, 8-32 X 1.25”,
PNHD, PHIL
ITEM QTY. PART NO. DESCRIPTION
323 4 HS-41006 SCREW, SLFTP, 10-24 X .5,
PNHD, PHIL
324 15 HS-41187 SCREW, SLFTP, 8-16 X .3125”,
PLASTITE
325 2 HX-20360 INSERT, EXPANSION, PLASTIC,
#8 - #1
326 1 PL-20143 HOUSING, E-STOP
328 1 PL-20210 CONSOLE, BACK PANEL
329 1 PL-20211 CONSOLE, JUNCTION COVER,
INNER, LEFT
330 1 PL-20218 DUCT, FAN, RIGHT
331 1 PL-20274 ISOLATOR, WATER, BOTTLE,
LEFT
332 1 PL-20275 ISOLATOR, WATER, BOTTLE,
RIGHT
333 1 PL-20340 DUCT, FAN, LEFT
334 1 PL-20355 COVER, JUNCTION, CONSOLE,
OUTER, LEFT
335 1 PL-20356 COVER, JUNCTION, CONSOLE,
INNER, RIGHT
336 1 PL-20357 COVER, JUNCTION, CONSOLE,
OUTER, RIGHT
337 1 PL-20550 CONSOLE, FRONT
338 1 SW-21183-X* MEMBRANE, 750T, KEYBOARD
345 1 PL-20549-X* BUTTON, STOP, MOLDED
346 1 AX-20513 SWITCH, BUTTON, STOP
347 4 HS-20553 SCREW, 4 X 3/8”, SLFTP, PNHD,
PHIL, ZN, PLASTITE
350 1 DE-20735-X* LABEL, WARNING, CONSOLE
351 2 KHX-21337 BOTTLE STABILIZER
352 1 DE-21596 LABEL, AV BLANK, 750T
352 1 SW-20813-X* MEMBRANE,AV KEYPAD
353 1 KAD-21926 PCA,PEM JACK BOARD
354 1 AF-21482 BRACKET,AV,LOWER,750T
355 1 KAF-21910 WELDMENT,AV,750T
356 1 AX-21798-X* ASSY,HANDSET,TOP W-TABS
357 6 HN-21072 PEM MOUNTING NUT
358 2 HS-11347 BOLT,1-4-20X0.75,SCHD BTN,BLK
359 2 HS-12083 BOLT LCK,1-4-20X.625
360 2 HS-13739 BOLT LCK,1-4-20X1.25,G5
362 1 PL-21792 COVER,HANDSET BOTTOM
363 1 PL-21793 COVER,HANDSET AV MODULE
364 1 PL-21794 COVER,HANDSET NON AV
MODULE
365 1 KAW-20820 KIT,C-HR REPLACEMENT
CONTACT GRIPS WITH
CONNECTOR WIRES
400 1 AD-21736 PCA, HANDSET, UNIVERSAL
401 1 AF-20137 BRACKET, A/V POWER SUPPLY
403 1 AW-21489 CABLE,CAT5E 24” PATCH,BLUE
404 1 AW-20241 POWER CORD, IEC NEMA 5-15,
SHORT FOR A/V
406 1 AW-21499 CABLE,LOCKING RF and DC
POWER CABLE,2795MM
408 1 CP-21072 MONITOR,13.3”, ATSC, NTSC,
PEM
409 1 FS-20300 STRAP, A/V POWER SUPPLY
416 1 PL-20278 CONSOLE TOP W/O A/V
418 1 TR-21881 POWER SUPPLY,12V FAN
LOCKING DC
419 1 FS-20233 BRACKET, FAN POWER SUPPLY
RETAINER
422 1 CP-21073 MONITOR,13.3”, DVB-T, SECAM,
PAL, PEM
423 1 PL-21178 CONSOLE, TOP, A/V, 751T
To Next Page
