CYBEX 770T Service Manual

2. Grasp the service wheel lever and slide to the right and down to lock in place.
Qty.DescriptionItem
1Service wheel lever1
1Frame2
The service wheel will lower and raise the rear feet off the floor.
Qty.DescriptionItem
1Service wheel1
2Rear feet2
1Floor3
1Service wheel lever4
3. Move treadmill as needed.
Disengage service wheel
Trip and fall hazard. To avoid injury, make sure service wheel lever is not
engaged prior to use.
1. Grasp the service wheel lever and slide to the right, lift up, and slide to the left.
Qty.DescriptionItem
1Service wheel lever1
1Frame2
2. Plug the power cord into the power outlet.
Service Schedule
All maintenance activities shall be performed by qualified personnel. Failure to do so could result in
serious injury.
Page 19 of 261
Cybex 770T/790T Treadmill Part Number

CYBEX 770T Specifications

General

Weight Capacity	400 lbs
Speed Range	0.5 - 12.4 mph
Incline Range	0 - 15%
Running Surface	22" x 60"
Heart Rate Monitoring	Yes
Display	15" Touch Screen
