CYBEX 770T Service Manual

2. Plug fan cable into connector (J19) on MCC board.
Qty.DescriptionItem
1Fan Cable1
1MCC Board2
1J193
1Fan4
Install back cover
Install the four screws securing the back cover to the console assembly using a Phillips screwdriver.
Qty.DescriptionItem
1Console Assembly1
1Back Cover2
4Screws3
Complete installation
1. Plug the power cord into the power outlet.
2. Verify the power cord is not being pinched under the front of the treadmill.
3. Operate the unit at all levels to verify proper operation.
Page 199 of 261
Cybex 770T/790T Treadmill Part Number

CYBEX 770T Specifications

General

Weight Capacity	400 lbs
Speed Range	0.5 - 12.4 mph
Incline Range	0 - 15%
Running Surface	22" x 60"
Heart Rate Monitoring	Yes
Display	15" Touch Screen
