CYBEX PLATINUM - Removing the Base from the Vehicle

32
• Unlock both ISOFIX connectors (5) through pushing the
buttons (6) and (7) simultaneously and pull them out of the
ISOFIX connect guides.
• Pull out the base from the ISOFIX anchorage points (2).
• Push the connectors (5) back into the original position.
• By pressing the adjustment button (9) you can push back
the load leg into its original position and then fold it back to
save space.
REMOVING THE BASE FROM THE VEHICLE
5
6 7
9
