48
5a
6a
7a
9a
REMOVING THE BASE Z ONE FROM THE VEHICLE
• Unlock both ISOFIX connectors (5a) through pushing the
buttons (6a) and (7a) simultaneously and pull them out of
the ISOFIX connect guides.
• Pull out the base from the ISOFIX anchorage points.
• Push the connectors (5a) back into the original position.
• By pressing the adjustment button (9a) you can push back
the load leg into its original position and then fold it back to
save space.
