00124 - Sliding Increment & Half Weight
1 1 11040-216 Belt Clamp
2 1 11040-301 Clamp Block Insert
3 3 4605-390 Increment Weight
4 1 51119 Selector Pin Retainer
5 1 BH030201 Quick Release Pin .375 Dia. x 4.00 Lg
6 2 HC702817 SHCS .375-16 x 1.00
7 2 HC702828 SHCS .375-16 x 2.25
8 4 HN704901 Nylon Locknut .375-16
9 4 HS347600 Washer SAE .375
10 1 4605-424 Caution Decal
11 1 Top Weight (See chart on previous page)
12 1 4700-240 Weight Mount
13 2 4700-318 Increment Weight Rod
14 1 4700-319 Increment Weight Frame Mount
15 2 4700-321 Rubber Washer
16 2 JC702820 SHCS .375-16 x 1.25
17 2 HS348300 Split Lockwasher .375
18 1 4701-001 Top Weight Guide
19 1 FB130208 Bearing Sleeve .68 x .81 1.00 Lg
20 3 HC702816 SHCS .375-16 x .875
21 3 HY740000 Set Screw
ITEM QTY PART NO. DESCRIPTION
Delivery
& Installation
Page 5-8
Cybex VR2 Owner’s Manual
