EN / CZone® COI – Combination Output Interface
5 SPECIFICATIONS
TECHNICAL SPECIFICATIONS 5.1
Model
Combination Output Interface
Article numbers
80-911-0119-00, 80-911-0120-00
Manufacturer
BEP Marine New Zealand
Output Channels High
4 x 25A
Output Channels Low
12 x 10A Dimmable
Analogue Inputs
8 x Analogue Inputs: Positive or Negative Switching, 0-32 Volt, 0-1000 Ohm Resistance
& 4-20mA Current
Additional Monitoring
2 x Voltage Sensors (Main Positive Stud & NMEA2000 Power)
Digital Switch Inputs
6 x Digital Inputs w Systems On/Backlighting via Digital Breakout
Circuit Current
Monitoring
All 16 Output Channels
Circuit Protection
Configurable Electronic Fuse + ATC Fuse
Alarms
Overcurrent, Short Circuit, Low Run Current, Fuse Tripped & Fuse In Over-ride alarms
Maximum Continuous
Current
150A @ 40°C (derating above 40°C)
NMEA 2000 Power
Consumption
250mA @12V, 180mA @12V standby
Power Supply
M8 (5/16") Stud Positive, M6 (1/4") Negative
Voltage
9-32V (with Power Available LED and Voltage Monitoring)
Circuit Bypass
Mechanical Protection/Bypass All Output Channels
Bilge Pump Circuits
4 x Channels High: Integrated manual control & pump running detection
Ingress Protection
IPx5 (mounted at 0°, +/-90°)
Communication
NMEA 2000
Weight
1.9kg
Certification
CE, ABYC, NMEA
NMEA 2000 PGN’S 5.2
NMEA 2000 PGN’s sent from the COI
PGN Number
Description
Fields
127508
Battery Status
Battery Voltage
127505
Fluid Level
Fluid Level
130312
Temperature
Actual Temperature
130314
Pressure
Pressure
130316
Temperature, Extended Range
Actual Temperature
