CZone COI - Product Dimensions

EN / CZone® COI – Combination Output Interface
22
DIMENSIONS 5.4
Figure 16. COI Dimensions no covers
Figure 17. COI Dimensions with covers
65 [2 9/16"]
69 [2 3/4"]
339 [13 5/16"]
235 [9 1/4"]
339 [13 3/8"]
339 [13 5/16"]
194 [7 5/8"]
68 [2 11/16"]
339 [13 3/8"]
1 2 3 4 5 6
12 11 10 9 8 7
1 2 3 4
8
7
6
5
1 2
34
