EN / CZone® DDS User & Installation Manual
8 Specifications
TECHNICAL SPECIFICATIONS
Specifications
Main Supply Voltage 12V/24V DC (9V-32V min/max)
Circuit protection MINI Blade Fuse, Max Interrupting Capacity 1000A, Max Voltage 32VDC
NMEA2000 connectivity 1 x CAN Micro-C port, 1 LEN
Switch Banks 2
Output wire range 0.5 - 2mm (14AWG – 20AWG)
Maximum current 60A 12V/24V Total Module Current
Power consumption sleep <120mA
Power supply M8 Positive Terminal (Max Torque 3.9Nm (34.5in/lbs))
Network Supply voltage 9-16V via NMEA2000
Circuit bypass Mechanical Bypass on Relay Output Channels
Ingress protection IP65 (with fuse cover in place)
Maximum Shock Resistance 20G
Compliance
Ignition Protected (with fuse cover in place)
CE, RCM, NMEA2000, UK-CA
Warranty period 2 years
Operating temperature range -25C to +70C (-13F to +158F)
Storage temperature range -40C to +85C (-40F to +185F)
Dimensions W x H x D 351.4mm x 164.5mm x 53.0mm
Weight 1040g (no connectors)
NMEA 2000 PGN’S
Temperature, Extended Range
