CZone DDS - DDS Overview; Figure 1. Product Overview

EN / CZone® DDS User & Installation Manual
8
DDS OVERVIEW
Component
1
LED Indicator
2
Circuit Fuses
3
Main Positive Supply Terminal (M8 Stud)
4
Connector A - AT06-12SA
5
Connector B - AT06-12SB
6
Connector C - AT06-12SC
7
Connector D - AT06-12SD
8
NMEA2000 Micro C Connector
9
Fuse Removal Tool
10
Fuse Panel Cover
Figure 1. Product Overview
2
3
4
10
5
6
7
8
1
9
