Section 2 - Conguration
You can input the wireless network name of the root AP
or click the Site Survey button to nd the root AP.
Click this button to choose the root AP from an available
connection list.
This option is unavailable in AP Client mode.
AP Client
This option is unavailable in AP Client mode.
Wireless
Network Name
(also called the
SSID):
Site Survey:
Wireless
Channel:
Enable Auto
Channel scan:
Enable Hidden
Wireless:
The channel used will be displayed. The channel will
follow the root AP.
In AP Client wireless mode, the DAP-1160 acts as a wireless network adapter for your Ethernet-enabled device (such as a game console
or a TV set-top box).
Wireless MAC
Clone:
MAC Address:
Scan:
Wireless
Security Mode:
Enabling this option allows the user to manually assign
the source MAC address to packets forwarded by the
DAP-1160. If not manually assigned, the packet’s source
MAC address eld will be automatically selected as the
DAP-1160’s MAC address.
Enter the desired MAC address connected to your DAP-
1160 to enable the clone function.
Click the Scan button to search for all available devices
connected to your DAP-1160’s Ethernet ports.
Select a wireless security setting. Options are None, WEP, WPA, or WPA2. See p.38 of this manual for a detailed
explanation of the wireless security options.
