D-Link DAP-1160 - Port Forwarding

25D-Link DAP-1160 User Manual
Section 2 - Conguration
Advanced
Port Forwarding
This function is available if the DAP-1160 is in WISP Client Router or WISP Repeater mode. This feature allows you to open a single port
or a range of ports. Click Save Settings and the port forwarding rule will be put into the Port Forwarding List.
Enter a name for the rule. You can select an
application name from the Application Name
drop-down menu. Click the << button to ll in
the Name eld with the application name that
you selected.
Name:
Enter the IP address of the computer on
your local network that you want to allow the
incoming service to.
IP Address:
Enter the port or ports that you want to open.
If you want to open one port, enter the same
port in both boxes.
Start Port/End
Port:
Select TCP, UDP, or Both.Trafc Type:
Check the box to congure a port forwarding
rule.
Port
Forwarding
Rules:
