Section 2 - Conguration
PPPoE
Choose PPPoE (Point-to-Point Protocol over Ethernet) if your ISP uses a PPPoE connection. Your ISP will provide you with a username
and password. This option is typically used for DSL services. Make sure to remove your PPPoE software from your computer. The
software is no longer needed and will not work through the DAP-1160.
Enter your PPPoE user name.
User Name:
Enter your PPPoE password and then
retype the password in the next box.
Password:
Enter the ISP Service Name (optional).
Service Name:
Enter a maximum idle time during which
the Internet connection is maintained
during inactivity.
Maximum Idle
time:
You may need to change the MTU
(Maximum Transmission Unit) for optimal
performance with your specific ISP. The
default MTU size is 1492.
MTU Size:
Select this option if you want the DAP-1160
to get the DNS (Domain Name System)
server IP address automatically.
Attain DNS
Automatically:
Select this option if you want to manually enter the DNS Server IP address(es). Fields to enter the Primary
and Secondary DNS server IP addresses will appear after you select this option.
Set DNS
Manually:
Primary DNS
Server:
Enter the Primary DNS server IP address assigned by your ISP.
Clone MAC
Address:
The default MAC address is set to the MAC address on the AP (Access Point). You can click the Clone Your
PC's MAC Address button to replace the AP's MAC address with the MAC address of your Ethernet card. It is not
recommended that you change the default MAC address unless required by your ISP.
This is optional.
Secondary DNS
Server:
Reconnection
Type:
Select Always on, On demand, or
Manual.
