D-Link DAP-1320 User Manual

27D-Link DAP-1320 User Manual
Section 3 - Conguration
IPv6 Device Management Interface: You can select Autoconguration (SLAAC/DHCPv6), Static IPv6, or Link-local only:
My IPv6
Connection is:
Obtain DNS
Server Address:
Primary DNS
Server:
Secondary DNS
Server:
Select Autoconguration (SLAAC/DHCPv6) to have the
DAP-1320 automatically receive an IPv6 address from the
uplink router.
You can select to Obtain IPv6 DNS Servers automatically,
or you can select Use the following IPv6 DNS Servers and
enter IPv6 DNS server addresses manually.
If you selected the second option above, enter the Primary
DNS Server address.
Enter the Secondary DNS Server address. This is optional
but will provide backup if the Primary DNS server fails.
My IPv6
Connection is:
IPv6 Address:
Subnet Prex
Length:
Default Gateway:
Primary DNS
Server:
Secondary DNS
Server:
Select Static IPv6 to manually assign an IP address to the
DAP-1320.
Enter the IPv6 Address that you want to assign to the
extended network AP. This address should be outside of the
uplink router’s DHCP address pool.
Enter the length of the IPv6 subnet prex.
Enter the Default Gateway. (Usually this is the IP address
of the uplink router.)
Enter the Primary DNS Server address.
Enter the Secondary DNS Server address. This is optional
but will provide backup if the primary server fails.

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
