D-Link DAP-1320 User Manual

57D-Link DAP-1320 User Manual
Appendix B - Networking Basics
Windows® 8 Users
• Press the Windows key and then type IP. Click Settings on the right side and then click View Network Connections.
• Right-click on the adapter which represents your D-Link wireless network adapter.
• Highlight Internet Protocol Version 4 (TCP /IPv4) and click
Properties.
• Click Use the following IP address and enter an IP address that is on
the same subnet as your network or LAN IP address on your router
or network.
Example: If the router’s LAN IP address is 192.168.0.1, make your IP
address 192.168.0.X where X is a number between 2 and 99. Make
sure that the number you choose is not in use on the network.
• Set Default Gateway the same as the LAN IP address of your router
or gateway.
• Set Primary DNS the same as the LAN IP address of your router or
gateway.
• The Secondary DNS is optional (you may enter a DNS server from
your ISP).
• Click OK to save your settings.
Statically Assign an IP Address
If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
