D-Link DAP-1320 User Manual

51D-Link DAP-1320 User Manual
Section 5 - Troubleshooting
• Congure your Internet settings:
• Go to Start > Settings > Control Panel. Double-click the Internet Options Icon. From the Security tab, click
the button to restore the settings to their defaults.
• Click the Connection tab and set the dial-up option to Never Dial a Connection. Click the LAN Settings button.
Make sure nothing is checked. Click OK.
• Go to the Advanced tab and click the Reset button to restore these settings to their defaults. Click OK three
times.
• Close your web browser (if open) and open it.
• Access the Web Management. Open your web browser and enter the IP address of your DAP-1320 in the address bar. This
should open the login page for your Web Management.
• If you still cannot access the conguration, unplug the device for 10 seconds and plug back in. Wait about 30 seconds and
try accessing the conguration. If you have multiple computers, try connecting using a dierent computer.
2. What can I do if I forgot my password?
If you forgot your password, you must reset your DAP-1320 Unfortunately, this process will change all your settings back to
the factory default settings.
To reset the DAP-1320, locate the reset button (hole) on the bottom of the unit. With the device powered on, use a paperclip
to hold the button down for 10 seconds. Release the button and the device will reboot. Wait about 30 seconds to access the
DAP-1320. The default IP address is 192.168.0.50. When logging in, the username is admin and leave the password eld empty.
Reset

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
