D-Link DAP-1610 User Manual

DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Overview
Product Appearance
Upper Panel
Figure 1. Upper panel view.
LED Mode Description
POWER/WPS
Solid red
The device is being loaded.
Solid green
The device is ready for use.
Blinking red
Attempting to add a wireless device via the
WPS function.
No light
The extender is powered off.
Wi-Fi Signal Strength
Solid red
The device is not connected to a wireless
network or the signal strength is poor.
Solid green
Fair signal strength.
Solid green
Good signal strength.
Solid green
Excellent signal strength.
No light
The 2.4GHz and 5GHz bands are off.
The Wi-Fi Signal Strength LED is a LED scale. It shows the signal strength of the wireless
network to which DAP-1610 is connected. The more LEDs are on, the better the signal strength is.
To improve the signal strength, move the extender closer to the source of the signal.
Page 10 of 91

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
