D-Link DAP-1610 User Manual

DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
MAC Filter
On the Wi-Fi / MAC Filter page, you can define a set of MAC addresses of devices which will be
allowed to access the WLAN, or define MAC addresses of devices which will not be allowed to
access the WLAN.
!
It is recommended to configure the Wi-Fi MAC filter through a wired connection to DAP-
1610 .
Figure 49. The page for configuring the MAC filter for the wireless network.
By default, the Wi-Fi MAC filter is disabled.
To configure the MAC filter, first you need to create rules (specify MAC addresses of devices for
which the specified filtering modes will be applied). To do this, click the ADD button.
Figure 50. The window for adding a rule for the MAC filter.
Page 63 of 91

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
