DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the Dynamic IP Addresses section, you can configure the built-in DHCP server of the
extender.
Figure 34. Configuring the local interface. The IPv4 tab. The Dynamic IP Addresses section.
Parameter Description
Dynamic IP Addresses
Mode of dynamic IP
address assignment
An operating mode of the extender's DHCP server.
Disable: the extender's DHCP server is disabled, clients' IP
addresses are assigned manually.
DHCP server: the extender assigns IP addresses to clients
automatically in accordance with the specified parameters. When
this value is selected, the Start IP, End IP, Lease time fields and
the DNS relay switch are displayed on the tab.
Start IP
The start IP address of the address pool used by the DHCP server to
distribute IP addresses to clients.
End IP
The end IP address of the address pool used by the DHCP server to
distribute IP addresses to clients.
Lease time
The lifetime of IP addresses leased by the DHCP server. At the end
of this period the leased IP address is revoked and can be distributed
to another device, unless the previous device has confirmed the need
to keep the address.
DNS relay
Move the switch to the right so that the devices connected to the
extender obtain the address of the extender as the DNS server
address.
Move the switch to the left so that the devices connected to the
extender obtain the address transmitted by the ISP or specified on
the Advanced / DNS page as the DNS server address.
When all needed settings are configured, click the APPLY button.
Page 39 of 91
