DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the opened window, specify the needed parameters:
Parameter Description
Speed
Data transfer mode.
Select the auto value to enable autonegotiation. When this value is
selected, the Autonegotiation Modes and Flow Control
sections are displayed.
Select the 10M-Half, 10M-Full, 100M-Half, or 100M-Full value
to manually configure speed and duplex mode for the selected port:
• 10M-Half: Data transfer in just one direction at a time (data
can be either sent or received) at the maximum possible rate
of up to 10Mbps.
• 10M-Full: Data transfer in two directions simultaneously
(data can be sent and received at the same time) at the
maximum possible rate of up to 10Mbps.
• 100M-Half: Data transfer in just one direction at a time (data
can be either sent or received) at the maximum possible rate
of up to 100Mbps.
• 100M-Full: Data transfer in two directions simultaneously
(data can be sent and received at the same time) at the
maximum possible rate of up to 100Mbps.
Autonegotiation modes
To enable the needed data transfer modes, move relevant switches to the right.
Flow control
Symmetric flow control
Move the switch to the right to enable the flow control function for
the port.
Move the switch to the left to disable the flow control function for
the port.
After specifying the needed parameters, click the SAVE button.
Page 70 of 91
