D-Link DCH-M225 User Manual

29D-Link DCH-M225 User Manual
Section 3 - Conguration
My IPv6
Connection is:
LAN IPv6 Link-
Local Address:
Select Link-local only to set an IPv6 address for only the
local network.
Displays the LAN IPv6 Link-Local Address of the DCH-M225.
My IPv6
Connection is:
IPv6 Address:
Subnet Prex
Length:
Default
Gateway:
Primary DNS
Server:
Secondary DNS
Server:
Select Static IPv6 to manually assign an IP address to the
DCH-M225.
Enter the IPv6 Address that you want to assign to the
extended network AP. This address should be outside of the
uplink router’s DHCP address pool.
Enter the length of the IPv6 subnet prex.
Enter the Default Gateway. (Usually this is the IP address
of the uplink router.)
Enter the Primary DNS Server address.
Enter the Secondary DNS Server address. This is optional
but will provide backup if the primary server fails.
IPv6 Device Management Interface (con’d)

D-Link DCH-M225 Specifications

General

Type	AV transmitter
Antenna type	Internal
Certification	FCC\\r IC\\r Wi-Fi Certified\\r CE
Product color	White
LED indicators	Yes
Maximum resolution	- pixels
Compatible products	DLNA, AirPlay
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
Audio input	1
Frequency	2400 MHz
Connector(s)	3.5mm Audio
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	110-125 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	81.6 g
Dimensions (WxDxH)	54.1 x 41.9 x 54.61 mm
