Setting up the DPR-2000
D-Link DPR-2000 - User Manual 11
Immediately after power-up, all LEDs should illuminate steadily for several seconds.
Then the USB LEDs should turn OFF simultaneously. Irregularity of any of the LEDs
during these LED tests may mean there is a problem with the LEDs themselves.
The actual component tests immediately follow the LED tests. A normal (no fault)
result is signaled by simultaneous flashing of the LEDs three times, followed by a
quiescent state with all LEDs dark.
If the Self-Test routine traps any component error, then following the LED tests the
Self-Test will halt and the LEDs will continuously signal the error according to the
following table. In the event of any such error signal, contact your dealer for
correction of the faulty unit.
USB LED Faulty Component
On DRAM error
1 long 3 short Flash Protected
1 long 5 short Flash Erase/Program error
1 long 6 short LAN Controller error
1 long 14 short LAN MII error
1 long 18 short USB error
