D-Link DSL-124 User Manual

19D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 3 - Getting Started
Step 3: Setup Internet Connection (Ethernet WAN)
This step of the wizard allows you to configure your DSL WAN Internet
connection type. Select the Protocol used by your ISP: PPPoE, Dynamic IP,
or Static IP.
If you selected Static IP, enter your Static IP information as supplied by your ISP. Click
Next to continue.
STATIC IP
PPPOE
If you selected PPPoE, a box will appear to enter your PPPoE username and
password. Once you have entered your PPPoE credentials, click Next to continue.
Note: Make sure to remove your PPPoE software from your computer. The software is no
longer needed and will not work through a router.
Bridge or Dynamic IP require no additional configuration. Click Next to continue.
BRIDGE/DYNAMIC

D-Link DSL-124 Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4GHz
LAN Ports	4 x 10/100Mbps
Security	WPA/WPA2
Antenna	2 x External Antennas
Wired Ports	1 x RJ-11 ADSL port
ADSL Standards	ADSL2/2+
