18D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 3 - Getting Started
This step of the wizard allows you to configure your DSL WAN Internet connection type.
Choose your Country and Internet Service Provider (ISP) from the drop down menu.
The necessary settings will automatically populate. If you cannot find your country or
ISP, select Others. You will need to enter the connection details, provided by your ISP,
manually. Select the Protocol used by your ISP: Dynamic IP, Static IP, PPPoE, PPPoA, or
Bridge, along with the Connection Type: VC-MUX or LLC and input the VPI, VCI, and
MTU settings.
Step 3: Setup Internet Connection (DSL WAN)
PPPOE/ PPPOA
If you selected PPPoE or PPPoA, a box will appear to enter your PPPoE/PPPoA username
and password. Once you have entered your PPPoE/PPPoA credentials, click Next to
continue.
Note: Make sure to remove your PPPoE software from your computer. The software is no
longer needed and will not work through a router.
If you selected Static IP, enter your Static IP information as supplied by your ISP. Click
Next to continue.
STATIC IP
Bridge or Dynamic IP require no additional configuration. Click Next to continue.
BRIDGE/DYNAMIC

D-Link DSL-124 Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4GHz
LAN Ports	4 x 10/100Mbps
Security	WPA/WPA2
Antenna	2 x External Antennas
Wired Ports	1 x RJ-11 ADSL port
ADSL Standards	ADSL2/2+
