D-Link DSL-2740E User Manual

DSL-2740E User Manual
35
The following table describes the parameters in this page.
Field
Description
Band
Choose the working mode of the modem. You can
choose from the drop-down list.
Mode
Choose the network model of the modem, which is
varied according to the software. By default, the
network model of the modem is AP.
SSID
The service set identification (SSID) is a unique name
to identify the modem in the wireless LAN. Wireless
stations associating to the modem must have the same

D-Link DSL-2740E Specifications

Data Transfer Rates

G.dmt full rate downstream	8 Mbps
G.dmt full rate upstream	1 Mbps
G.lite downstream	1.5 Mbps
G.lite upstream	512 Kbps
G.dmt.bis full rate downstream	12 Mbps
G.dmt.bis full rate upstream	12 Mbps
ADSL full rate downstream	24 Mbps
ADSL full rate upstream	1 Mbps

Media Interface

ADSL interface connector type	RJ-11
LAN interface port type	RJ-45
Ethernet connection type	10/100BASE-T
