D-Link DSL-2740E User Manual

DSL-2740E User Manual
43
The following table describes the parameters in this page.
Field
Description
Fragment
Threshold
Used to fragment packets which help improve
performance in the presence of radio frequency (RF)
interference.
RTS Threshold
(Request to
Send
Threshold)
Determines the packet size of a transmission through
the use of the router to help control traffic flow.
Beacon Interval A packet of information that is sent from a connected
device to all other devices where it announces its

D-Link DSL-2740E Specifications

Data Transfer Rates

G.dmt full rate downstream	8 Mbps
G.dmt full rate upstream	1 Mbps
G.lite downstream	1.5 Mbps
G.lite upstream	512 Kbps
G.dmt.bis full rate downstream	12 Mbps
G.dmt.bis full rate upstream	12 Mbps
ADSL full rate downstream	24 Mbps
ADSL full rate upstream	1 Mbps

Media Interface

ADSL interface connector type	RJ-11
LAN interface port type	RJ-45
Ethernet connection type	10/100BASE-T
