DSL-2740E User Manual
50
The following table describes the parameters and buttons of this page:
Field Description
Direction Select
Select the router interface. You can select LAN or
WAN. In this example, LAN is selected.
LAN ACL Switch Select it to enable or disable ACL function.
IP Address
Enter the IP address of the specified interface. Only
the IP address that is in the same network segment
with the IP address of the specified interface can
access the router.
Services Allowed
You can choose the following services from LAN:
Web, Telnet, SSH, FTP, TFTP, SNMP and PING.
You can also choose all the services.
Add
After setting the parameters, click it to add an entry
to the Current ACL Table.
Reset Click it to refresh this page.
When the direction of data packets is set to WAN, the page shown in the following
figure appears.
