D-Link DSL-2740E User Manual

DSL-2740E User Manual
51
The following table describes the parameters and buttons of this page:
Field Description
Direction Select
Select the router interface. You can select LAN or
WAN. In this example, WAN is selected.
WAN Setting You can choose Interface or IP Address.
WAN Interface
Choose the interface that permits data packets from
WAN to access the router.
Services Allowed
You can choose the following services from WAN:
Web, Telnet, SSH, FTP, TFTP, SNMP and PING.
You can also choose all the services.

D-Link DSL-2740E Specifications

Data Transfer Rates

G.dmt full rate downstream	8 Mbps
G.dmt full rate upstream	1 Mbps
G.lite downstream	1.5 Mbps
G.lite upstream	512 Kbps
G.dmt.bis full rate downstream	12 Mbps
G.dmt.bis full rate upstream	12 Mbps
ADSL full rate downstream	24 Mbps
ADSL full rate upstream	1 Mbps

Media Interface

ADSL interface connector type	RJ-11
LAN interface port type	RJ-45
Ethernet connection type	10/100BASE-T
