5. IP Sharing Functions
All Gateway series have a built-in IP sharing function. The settings and instructions at a PC end are
described below:
Current Intranet only supports static IP mode, and the settings at the PC end are as follow:
Available IP address Range : 192.168.8.1 – 192.168.8.253 (default address of Gateway is
192.168.8.254)
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.8.254
The above values vary with different LAN Port Settings.
Assume Gateway’s LAN settings are,
IP address : 192.168.3.1
Subnet Mask : 255.255.255.0
Then, the settings at PC end should be as follows:
Valid IP address range : 192.168.3.2 – 192.168.3.254
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.3.1
WAN Port
Connected to
Internet
LAN Port connected to
Intranet
