D-Link DXS-1210 Series Hardware Installation Guide

DXS-1210 Series 10 Gigabit Ethernet Smart Managed Switch Hardware Installation Guide
22
Performance Specification
Feature
Description
Switching Capacity
DXS-1210-28T
680 Gbps
DXS-1210-28S
560 Gbps
MAC Address Table
Up to 32K entries (256 static MAC addresses)
Transmission Method
Store and forward
Packet Buffer
DXS-1210-28T
4 MB
DXS-1210-28S
4 MB
Packet Forwarding
Rate
(Maximum)
DXS-1210-28T
505.92 Mpps
DXS-1210-28S
416.64 Mpps
Priority Queues
Supports the following:
 Maximum of 8 Priority Queues per port
Link Aggregation
Supports the following:
 Maximum of 8 groups per device
 Maximum of 8 ports per group
Static Routes
Supports the following:
 Maximum of 128 static IPv4 routes (shared with IPv6)
 Maximum of 64 static IPv6 routes (shared with IPv4)
Access Control List
(ACL) Entries
Supports the following:
 Maximum of 1536 ingress ACL entries
 Maximum of 1024 egress ACL entries
Port Type Specifications
Feature
Description
Console Port
The RJ45 console port provides out-of-band access to the CLI using the following
settings:
Baud Rate
115200 (default), 19200, 38400, and 9600 bps
Data Bits
8
Stop Bit
1
Parity
None
Flow Control
None
RJ45 Ports
The RJ45 Ethernet ports provides in-band access to SNMP, the CLI and Web UI,
interconnect nodes, and support the following standards and features:
Standards
IEEE 802.3u (100BASE-TX)
IEEE 802.3ab (1000BASE-T)
IEEE 802.3an (10GBASE-T)
IEEE 802.3az (Energy-Efficient Ethernet)
IEEE 802.3x (Full-Duplex, Flow Control)
The following features are supported on the RJ45 ports:
 Full-duplex operations on 100BASE-TX ports
 Head-of-line blocking prevention
 Manual/auto MDI/MDIX configuration
 Auto-Negotiation for each port

D-Link DXS-1210 Series Specifications

General

Product Series	DXS-1210
Power Supply	Internal
Jumbo Frame Support	9KB
Number of Ports	12
Layer	L2+
Form Factor	Rack-mountable
Uplink Ports	10G SFP+
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
