D-Link DXS-1210 Series Hardware Installation Guide

DXS-1210 Series 10 Gigabit Ethernet Smart Managed Switch Hardware Installation Guide
23
Port Type Specifications
SFP+ Ports
The SFP+ transceiver ports provides in-band access to SNMP, the CLI and Web UI,
interlink network segments, and support the following standards and features:
Standards
IEEE 802.3z (1000BASE-X)
IEEE 802.3ah (1000BASE-BX10)
IEEE 802.3ae (10GBASE-R)
All SFP+ ports are backwards compatible to support SFP transceivers. For the full list of
D-Link transceivers that are supported on the Switch, refer to the Supported
SFP/SFP+/SFP28 Transceivers table on page 23.
SFP28 Ports
The SFP28 transceiver ports provides in-band access to SNMP, the CLI and Web UI,
interlink network segments, and support the following standards and features:
Standards
IEEE 802.3ae (10GBASE-R)
IEEE 802.3by (25GBASE-R)
All SFP28 ports are backwards compatible to support SFP+ transceivers. For the full list
of D-Link transceivers that are supported on the Switch, refer to the Supported
SFP/SFP+/SFP28 Transceivers table on page 23.
Supported SFP/SFP+/SFP28 Transceivers
SFP Fiber Transceivers
Product Code
Standard
Mode
Distance
TX
RX
DEM-310GT
1000BASE-LX
Single-mode
10 km
1310 nm
DEM-311GT
1000BASE-SX
Multi-mode
550 m
850 nm
DEM-312GT2
1000BASE-SX
Multi-mode
2 km
1310 nm
DEM-314GT
1000BASE-LHX
Single-mode
50 km
1550 nm
DEM-315GT
1000BASE-ZX
Single-mode
80 km
1550 nm
SFP+ Fiber Transceivers
Product Code
Standard
Mode
Distance
TX
RX
DEM-431XT
10GBASE-SR
Multi-mode
300 m
850 nm
DEM-432XT
10GBASE-LR
Single-mode
10 km
1310 nm
DEM-433XT
10GBASE-ER
Single-mode
40 km
1550 nm
DEM-434XT
10GBASE-ZR
Single-mode
80 km
1550 nm
SFP28 Fiber Transceivers
Product Code
Standard
Mode
Distance
TX
RX
DEM-S2801SR
SFP28-25GB-SR
Multi-mode
100 m
850 nm
DEM-S2801LR
SFP28-25GB-LR
Single-mode
10 km
1310 nm
SFP Copper Transceivers
Product Code
Standard
Connector
Distance
TX/RX
Power
Amps
DGS-712
1000BASE-T
SFP to RJ45
100 m
-
3.3 V
375 mA
SFP+ Copper Transceivers
Product Code
Standard
Connector
Distance
TX/RX
Power
Amps
DEM-410T
10GBASE-T
SFP+ to RJ45
30 m
-
3.3 V
780 mA
WDM (BiDi) SFP Transceivers
Product Code
Standard
Mode
Distance
TX
RX
DEM-330T
1000BASE-BX-D
Single-mode
10 km
1550 nm
1310 nm

D-Link DXS-1210 Series Specifications

General

Product Series	DXS-1210
Power Supply	Internal
Jumbo Frame Support	9KB
Number of Ports	12
Layer	L2+
Form Factor	Rack-mountable
Uplink Ports	10G SFP+
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
