DXS-3400 Series Lite Layer 3 Stackable 10GbE Managed Switch Hardware Installation Guide
25
Figure 3-4 Duplex Chain stacking topology (SFP+)
The figure below illustrates how switches can be stacked in a Duplex Ring formation using Category 6a cables with
RJ45 connectors where the 2-port stacking configuration is used.
Figure 3-5 Duplex Ring stacking topology (RJ45)
The figure below illustrates how switches can be stacked in a Duplex Ring formation using optical fiber cables
connected to SFP+ transceivers or DAC with SFP+ connectors where the 2-port stacking configuration is used.
