D-Link DXS-3400 SERIES Hardware Installation Guide

DXS-3400 Series Lite Layer 3 Stackable 10GbE Managed Switch Hardware Installation Guide
37
Appendix A - Technical Specifications
General
Feature
Description
Data Transfer Rates
Full-duplex
Fast Ethernet
200 Mbps
Gigabit Ethernet
2 Gbps
10 Gigabit Ethernet
20 Gbps
Physical Stacking
Stacking Topology: Duplex Ring, Duplex Chain
Stacking Bandwidth: Up to 80 Gbps
Stacking Ports: Up to 4 switches can be stacked using the 10 Gbps
RJ45/SFP+ combo ports
Backup Master Support: Yes
Network Cables
UTP/STP Category 5, 5e for 100BASE-TX
UTP/STP Category 5e for 1000BASE-T
UTP/STP Category 6a for 10GBASE-T
EIA/TIA-568 100-ohm screened twisted-pair (STP) (100 m)
Physical and Environmental
Feature
Description
AC Power Supply
AC Input: 100~240 VAC, 50~60 Hz, 2 A
DC Power Supply
DC Input: -48 VDC, 5.2 A
Real Time Clock (RTC)
Be able to maintain the time setting when the device power is off
Fans
3 removable fan modules, front-to-back airflow
USB Slot
Supports a USB 2.0 Type-A flash drive with a maximum current of 1 A.
This slot only supports FAT16 and FAT32 file system architectures
Power Consumption
DXS-3400-24TC: 159.82 Watts (Max.), 85.1 Watts (Standby)
DXS-3400-24SC: 118.6 Watts (Max.), 64.8 Watts (Standby)
Temperature
Operating: -5 °C to 50 °C (23 °F to 122 °F)
Storage: -40 °C to 70 °C (-40 °F to 158 °F)
Humidity
Operating: 0 % to 95 % RH (non-condensing)
Storage: 0 % to 95 % RH (non-condensing)
Heat Dissipation
DXS-3400-24TC: 544.9862 BTU/Hr
DXS-3400-24SC: 404.426 BTU/Hr
