DIR-100 Ethernet Broadband Router
A
Technical Specifications
Standards
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3 Nway Auto-Negotiation
Device Management
Web-Based – requires at least Microsoft Internet Explorer v5 or later,
Netscape Navigator v4 or later, or other Java-enabled browsers.
Media Access Control
CSMA/CD
LEDS
Power
Status
WAN
Local Network – 10/100
Operating Temperature
32*F to 104*F (0*C to 40*C)
Humidity
95% maximum (non-condensing)
Power Input
External power Supply
DC 5V, 1.2A
Dimensions
L = 5.83in (148mm)
W = 4.5in (114mm)
H = 1.26in (32mm)
Weight
0.51 lbs (230g)
56

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link Ethernet Broadband Router DIR-100 and is the answer not in the manual?

D-Link Ethernet Broadband Router DIR-100 Specifications

General IconGeneral
CategoryWireless Router
ModelDIR-100
Connectivity TechnologyWired
Data Link ProtocolEthernet, Fast Ethernet
WAN Ports Qty1
LAN Ports Qty4
StandardsIEEE 802.3, IEEE 802.3u
Ports4 x 10/100Base-TX LAN, 1 x 10/100Base-TX WAN
SecurityNAT
Power5 V DC
Operating Temperature0 - 40 °C
Storage Temperature-20 °C to 70 °C
Humidity10 - 90% non-condensing
