D-Link ShareCenter DNS-325

9D-Link ShareCenter DNS-325 User Manual
Section 1 - Product Overview
Hardware Overview
Front Panel
COMPONENT DESCRIPTION
USB LED This light will illuminate when a USB device is inserted into the USB Port. When there’s trac this light will blink.
HDD LEDs
These lights will be solid when the drives are connected but inactive. The lights will blink when the drives are being
accessed, formatted or synchronized. They will illuminate AMBER if a drive has failed.
Power Button Press once to power on the device. To power down, press and hold the button until it begins to blink.
Drive Bays
With the front cover o, SATA hard drives can be slid in and out of the of device. Use the tabs on the rear of the device
to initially push a hard drive out.
Power Button
HDD LED (R)
Drive Bays
HDD LED (L)
USB LED
