D-Link Wireless N User Manual

5D-Link DIR-815 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect 10/100 Ethernet devices such as computers, switches, and hubs.
2 Internet Port
The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL
modem.
3 Reset Button Pressing the Reset button restores the router to its original factory default settings.
4 Power Button Use this switch to power on/power o the device.
5 Power Receptor Receptor for the supplied power adapter.
1 2 3 4 5

D-Link Wireless N Specifications

General

Frequency Band	2.4 GHz
Wireless Speed	Up to 300 Mbps
Security	WPA, WPA2, WEP
Firewall	NAT
Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
