D-Link Wireless N User Manual

36D-Link DIR-815 User Manual
Section 3 - Conguration
DS-Lite
Another Internet Connection type is DS-Lite.
DS-Lite
Conguration:
Select the DS-Lite DHCPv6 option to let the router allocate the
AFTR IPv6 address automatically. Select the Manual Conguration
to enter the AFTR IPv6 address in manually.
AFTR IPv6
Address:
After selecting the Manual Conguration option above, enter the
AFTR IPv6 address used here.
B4 IPv4 Address: Enter the B4 IPv4 address value used here.
WAN IPv6
Address:
Once connected, the WAN IPv6 address will be displayed here.
IPv6 WAN
Default Gateway
Once connected, the IPv6 WAN Default Gateway address will be
displayed here.
DS-Lite is an IPv6 connection type. After selecting DS-Lite, the following parameters will be available for conguration:

D-Link Wireless N Specifications

General

Frequency Band	2.4 GHz
Wireless Speed	Up to 300 Mbps
Security	WPA, WPA2, WEP
Firewall	NAT
Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
