D-MAX STANDALONE H.264 - 12 APPENDIX ∙ Specification

52
11. APPENDIX
ITEM 4CH
Video Video format NTSC/PAL
Video inputs 4CH
Compression H.264
Video outputs Composite (1) , VGA (1)
Playback Split / Full screen
Record Speed NTSC : 120fps, PAL : 100fps
Frame D1 (30 fps) / Half D1 (60 fps) / CIF (120 fps)
Event Continuous, Schedule, Motion, Sensor
Audio In/Out 4/1
Alarm In/Out 4/1
Network Communication LAN [10/100, Ethernet (RJ45)]
CODEC H.264 ( Dual Codec)
Protocol TCP/IP, DHCP
Other Remote access CMS, Web browser, Smart Phone App.
P/T/Z control Yes(RS-485)
Backup USB Pen Drive
USB 2.0 support 2 ports
HDD Max. 1 x internal HDD
Temp. 0℃ ~ 40℃
Power supply DC 12V 3.5A, Adapter
Dimension 338mm(W) x 58mm(H) x 220mm(D)
Unit weight 2.0Kg
SPECIFICATION
