D-Teg TX4000B - Axis Adjustments by Device Positions; Adjusting Axes for Upright and Upside Down Positions

14
Axis Adjustments by Device Positions
Driving Direction
F
: Front
RR
: Rear
T
: Top
B
: Bottom
R
: Right-side
L
: Left side
T
L
B
RRF
X: 0, Y: 0, Z:0
T
L
B
FRR
X: 0, Y: 0, Z:180
1) When device is in an upright position
T
F
B
LR
X: 0, Y: 0, Z:270
T
RR
B
RL
X: 0, Y: 0, Z:90
2) When device is in an upside down position
B
L
T
RRF
X: 180, Y: 0, Z:0
B
L
T
FRR
X: 180, Y: 0, Z:180
B
F
T
LR
X: 180, Y: 0, Z:270
B
RR
T
RL
X: 180, Y: 0, Z:90
