D-Teg TX4000B - SPECIFICATION; Technical Specifications of TX4000 Recorder

43
SPECIFICATION
Video In
CH1, CH2: 5V 1080P or 720p AHD camera in
CH3: 5V 720P AHD camera in
CH4: 5V D1 camera in
Audio In 1CH (Internal or External Microphone)
AV Out 1 Video out, 1 Audio out
Band support
WCDMA Band1(2,100MHz)/ Band8 (900MHz)
Max Data Rate
UL:5.76Mbps, DL : 7.2Mbps
Video resolution
1080p HD (1920x1080), 720P (1280x720),
D1(NTSC:720x480, PAL 720x576)
Recording Speed
Full HD: 30fps(25fps), HD: 60fps(50fps)
D1: Up to 120 fps (NTSC) or 100fps(PAL)
Recording Mode Continuous , Event, Dual Mode
Memory
Support 32GB, 64GB(FAT32), 128GB(FAT32)
GPS/GLONASS External GPS /GLONASS
G-Sensor Internal 3-axis G-sensor
Gyro 3Axis(X,Y,Z), output rate:100 Hz,
RTC Internal battery
Alarm In/Out 3 x Alarm In, 2 x Alarm Out
Remote controller 3x LED, Panic button, M1 & M2 button
LED
Green LED (Network), Blue LED (Record),
Network (Red LED)
Super Capacitor Enable recording of last file and shut down
Power input DC 12V/24V 3A
Delayed Power
Shutdown
Supports Delayed Power Shutdown
Power consumption Max. 36W
Size / Weight 120mm X 28mm X 90mm / 166g
Operation Temp. -10℃~55℃
