D-Teg TX4000B - Adjusting Axes for Top Facing Front;Rear Positions

16
Axis Adjustments by Device Positions
5) When device is in a sideway position with the TOP facing front
L
R
B
T
X: 90, Y: 0, Z:270
R
L
B
T
X: 270, Y: 0, Z:90
F
RR
B
T
X: 180, Y: 90, Z:0
R
6) When device is in a sideway position with the TOP facing rear
R
L
T
B
X: 270, Y: 0, Z:270
L
R
T
B
X: 90, Y: 0, Z:90
F
RR
T
B
X: 0, Y: 90, Z:0
L
REMARK: Do no install the device with the Front facing down position.
