9. Connect the display to the RVP-TDA3x system using the provided cable 1000285, HDMI-

Mini HDMI. The full-size HDMI end of the cable plugs into the monitor, and the Mini

HDMI end plugs into the RVP-TDA3x system.

The monitor’s other cable is the power cable. The monitor takes 12V DC from the power

supply provided in the monitor box. Locate the power port on the monitor, which is the

barrel jack at the very top of the monitor port panel.

a) HDMI connected

to back of

monitor

b) HDMI Mini

connected to

RVP-TDA3x

system

c) Monitor with

Power and HDMI

plugged in
