3.2 | Water outlet
Plug the water drain hose to the back of Bob.
Warning: To prevent leaks, please use the provided
clamp to fix the water outlet.
Connect the water outlet hose to a siphon
drain pipe (usually accessible under the sink)
Warning: The waste water coming out of Bob can
reach high temperature of up to 70°C.
1
Siphon drain pipe
Tighten the clamp screw with the supplied Bob
screwdriver/bottle opener and use the key ring to
tighten the screw! Then attach it to your key ring.
Pretty handy, as it will from now on follow you
everywhere as a bottle opener or screwdriver.
Warning: Do not block the water inlet of
the water tank. This must always remain
free.
2 options for evacutaing the waste water
6
QUICK SET-UP GUIDE
