5. APPLICATIONS
EVOSTA2, EVOSTA3 series circulators allow integrated adjustment of the differential pressure which enables
the circulator performance to be adapted to the actual requirements of the system. This determines
considerable energy saving, a greater possibility of control of the system, and reduced noise.
EVOSTA2, EVOSTA3 circulators are designed for the circulation of:
– water in heating and conditioning systems.
– water in industrial water circuits.
– domestic water only for the versions with bronze pump body.
EVOSTA2, EVOSTA3 circulators are self-protected against:
– Overloads
– Lack of phase
– Excess temperature
– Over-voltage and under-voltage
6. TECHNICAL DATA
Supply voltage
1x230 V(+/-10%), 50/60 Hz
Absorbed power
See electrical data plate
Maximum current
See electrical data plate
Grade of protection
IPX5
Protection class
F
TF Class
TF 110
Motor protector
No external motor protector is needed
Maximum environment temperature
40 ºC
Liquid temperature
-10 ºC ÷ 110 ºC
Flow rate
See Table 3
Head
See Table 3
Maximum working pressure
1.0 Mpa – 10 bar
Minimum working pressure
0.1 Mpa – 1 bar
Lpa [dB(A)]
≤ 43
Table 2: Technical data
Designation index
(example)
EVOSTA
40-70/
130
½”
X
Series name
Maximum head range (dm)
Centre distance (mm)
½” = 1”½ threaded outlets
= 1” threaded outlets
Standard (no ref.) = 1½” threaded outlets
½” = 1” threaded outlets
X = bocche filettate da 2”
