DAELIM DAYSTAR User Manual

<HEADLIGHT HIGH-BEAM INDICATOR>
Turned on when the headlight is in high-
beam position.
<NEUTRAL INDICATOR>
Turned on when the main switch is in
“ON” position and transmission gear in
neutral position.
<WINKER INDICATOR>
Blinks when turn signal is flashing.
Indicates amount of gasoline in fuel tank.
If needle is within E mark(red zone),
immediately fill gasoline.
●Fuel Capacity:17.3ℓ
●Reserve fuel capacity:2.9ℓ
11
INDICATOR LAMPS FUEL GAUGE
●Pay particular attention because
idle engine running or abrupt
acceleration in the 1st or 2nd gear
may cause the tachometer needle to
be in the danger zone(red zone).
Danger zone means the engine
revolution limit and, if engine is
run beyond this danger limit,
engine will be damaged.
WINKER
INDICATOR
FUEL GAUGE
HEAD LIGHT HIGH-BEAM
INDICATOR
NEUTRAL
INDICATOR
**vl125(~47P) 02.11.5 4:33 PM 페이지11

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
