<LEVER FREE PLAY INSPECTION>
Pull clutch lever until you feel resistance,
and using a graduated ruler, check the lever
end free play to verify it is within prescribed
level.
<CLUTCH OPERATION>
●When engine is idling, pull clutch lever
all the way and see if there is abnormal
noise or if you feel unusual heaviness.
●Slowly release clutch lever and start.
Check at this time to see if clutch is
engaged smoothly without slipping.
<CLUTCH LEVER ADJUSTMENT>
Adjust lever free play by using the clutch
cable’s clutch lever side or clutch side
adjuster.
●To make major adjustment, loosen the
clutch side lock nut and adjust by
operating the adjuster.
●For fine adjustment, loosen the clutch
lever side lock nut and turn adjuster.
●After adjusting, tighten lock nut. After
adjustment is completed, pull clutch
lever with hands until you feel
resistance and verify the lever free play
is within prescribed level.
CLUTCH LEVER FREE PLAY:
10~20mm
■
MAJOR ADJUSTMENT
■
FINE ADJUSTMENT
30
CLUTCH
CAUTION
●Upon completion of adjustment,
start engine and verify gear change
pedal is operating smoothly.
10~20mm
ADJUSTER
ADJUSTER
LOCK NUT
LOCK NUT
**vl125(~47P) 02.11.5 4:34 PM 페이지30

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
