DAELIM DAYSTAR User Manual

There is a tool box inside the right front
side cover. Safeguard tools inside the tool
box.
<HOW TO USE>
Use main switch key to open or close the
tool box cover.
<REFULELING>
●Open key cover ; insert main switch key
; turn key to right and fuel tank cap is
opened.
●Fill gasoline up the bottom of level plate
located at the lower side of tank mouth.
●Push the tank cap correctly with hands
and remove the main switch key. (If the
fuel tank cap is not locked, the main
switch key will not be removed)
FUEL CAPACITY : 17.3ℓ
16
TOOL BOX FUEL
CAUTION
●Make sure to stop engine and stay
away from fire when fueling.
●If gasoline is filled aboved the level
plate bottom, gasoline may
overflow.
TOOL BOX
KEY COVER
FUEL TANK CAP
MAIN SWITCH KEY
CAUTION
●Put tools inside the tool box,
and lock it with O-ring as noise
might occur while the vehicle is
moving
**vl125(~47P) 02.11.5 4:33 PM 페이지16

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
