Turn off main switch and check fuse for
sign of cut.
● Remove the four flange bolts, and take
off the right lower cover.
●Fuse is installed inside fuse holder
located near battery.
●To separate fuse, open fuse holder, hold
both ends of fuse cord and pull up, and
pull out the fuse connector crosswise.
●If the newly replaced fuse is burned
again soon, it is an indication of trouble.
45
FUSE REPLACEMENT
CAUTION
●Turn the ignition switch OFF
before checking or replacing fuse to
prevent accidental short-circuiting.
●When disassemble fuse, make sure
that fuse holder isn’t separated.
●After assembling fuse in the part of
connector, check if fuse moves
easily to a line. If fuse moves
easily, it may cause an accident at
heating.
●When replacing any of the electrical
parts (lights and gauges), be sure to
replace them with the recommended
parts. Using different parts can lead
to the fuses burning out or damage
to the battery.
●When washing the motorcycle take
special card not to allow to be
splashed in the area of the fuse.
WARNING
●Never use a fuse with a different
rating from that specified. Serious
damage to the electrical system or a
fire may result, causing a dangerous
loss of lights or engine power.
FUSE HOLDER
<DISASSEMBLY> <ASSEMBLY>
FUSE CONNECTOR
CORD
